SB4 Recumbent Bike
www.smoothfitness.co.uk
HARDWARE CHART
NO. DESCRIPTION QTY.
116 M6 SPRING WASHER 4
118 M8 SPRING WASHER 22
120 ROUND ALLEN HEAD BOLT M8x15MM 14
122 ROUND ALLEN HEAD BOLT M8x20MM 4
123 ROUND ALLEN HEAD BOLT M8x90MM 16
127 ROUND ALLEN HEAD BOLT M6x12MM r 4
129 ROUND PHILIPS HEAD MACHINE M5x15MM 2
132 SCREW M5 x 25MM 2
139 SCREW M5 x 20MM 2
140 SCREW M6 x 15MM 4
144 SCREW M5 x 20MM 4
154 FLAT WASHER (ID-6 x OD-6MM) 4
157 FLAT WASHER (ID-8 x OD-16MM)l 22
