IWS/ ICS 82 Stereo Re:sound I
23
INSTALLATION - I
NSTALLATION
Info
The IWS/ ICS82
has integrated
rotary tensioners for quick installation.
These rotary tensioners are located on
the rear of the speaker and swivel out
through 90° once the 4 marked screws
(see figure next page) on the front of
the speaker are screwed in.
The power should be switched of when
installing the speaker.
I
NSTALLATION
Step 1
Connect the speaker cable (right and
left channel), with the correct
polarity, using the pluggable screw
connectors.
Step 2
Insert the screw connectors in the
corresponding sockets (IN1 + IN2),
which are located on the crossover
board on the back of the speaker (see
below).
Revox fitted speaker:
Don’t forget the sound proofing
material.
Step 3
Insert the fitted speaker into the
opening and tighten the 4 rotary
tensioner screws a little, until the
speaker flange is held in position at
the sides. Under no circumstances
should the speaker flange be twisted.
Step 4
Place the speaker grille in position.

Speaker polarity
If a channel (IN1 / IN2) is connected
with reversed polarity, this results in
a loss of bass reproduction together
with an imprecise and diffused sound
picture.
