2. Specifications
Type VDA-4A
Art. No. 75101
Video standard PAL/NTSC
Video inputs 1.0 ~ 2.0Vp-p (C)VBS, 75ohms, BNC
Video outputs 4x 1.0 ~ 2.0Vp-p, (C)VBS, 75ohms, BNC
Distributor configuration 1 input to 4 outputs
Video signal bandwidth 0 ~ 10MHz (+/-3db)
Tilt 1% at 50Hz
Internal adjustments 1 Potentiometer each for the stepless
adjustment of the linear and HF gain
Signal pre-equalization range
(HF gain) 0 ~ 6.0db stepless adjustable (common for
all outputs)
Signal-to-noise ratio 55dB
Signal pre-amplification range
(linear gain) 0 to 6.0db stepless adjustable (common for
all outputs)
Temperature range 0 ~ +50°C
Supply voltage 230VAC/50Hz
Power consumption 3watts
Housing Steel metal
Colour Pantone Cool Gray 1C
Dimensions (HxWxD) 44x108x135mm
Weight 600g
