11 FBC 7 A1
GB
Inserting/replacing the batteries
♦ Unlock the battery compartment and pull the battery compart-
ment down and out of the appliance.
♦ Remove the discharged batteries.
♦ Insert 2 Type AA batteries (LR06-Mignon) into the battery
compartment. Ensure that the polarities are correct.
♦ Push the battery compartment back in the appliance until it
clicks into place.
The display is switched on, the system time starts at 0:00 and
the hour display blinks for a short time.
General Description
Appliance overview
See in addition the illustrations on the fold-out side.
Display
2 Rotary knob: change adjustable values
3 Button M
4 Button
5 Button ON/OFF
6 Coupling nut
7 Jumper
8 Terminals for a rain sensor
9 Hose connection
10 Battery compartment
11 Adapter G1" to G3/4"
12 Coupling unit
