Smoke Factory Spaceball II Fog Machine (120V) Benutzerhandbuch

Seite 6

Advertising
background image

4 Bezeichnung des Gerätes

4 Description of the device

6

[1] Nebelaustrittsöffnung

[2] Bedienfeld (Einstellen DMX-Startadresse, Regelung Output)

[3] Analog-Buchse

[4] DMX in/out
[5] Schnellkupplung für Fluidschlauch

[6] Kanisterdeckel

[7] Belüftungsventil

[8] Sinterfilter

[1] Fog nozzle

[2] Control panel (adjust DMX start address, control output)

[3] Analog socket

[4] DMX in/out
[5] Snap-on connector for fluid tube

[6] Canister cap

[7] Venting valve

[8] Sinter filter

[2]

[1]

[3]

[4]

[5]

[6]

[8]

[7]
