REMKO RKL 300 - Handbuch (Seite 13)

Elektrisches Anschlussschema
CM
PE N L
CX1
SM M1 CM
M2
CX3
CX2
OLP
AC2
WM
AC1
CN1
CN5
CN4
TH
MS1
P001B
P002B
CN2
PCB2
PCB1
R BK
BU
BU
BR
W BU
BU
BU
R
R
R
GR
BK
BR BR
CN3
KM
MS2
BU
BR
BK
Y
C
S R
OR W BU Y
BU
BR
BK
Y
Legende
PCB1 = Bedientableau
PCB2 = Steuerplatine
SM = Swing-Motor
M1 = Ventilatormotor (Verdampfer)
M2 = Ventilatormotor (Verflüssiger)
KM = Kondensatpumpe
CM = Kompressor
OLP = Kompressorschutz
CX1 = Kondensator (M1)
CX2 = Kondensator (M2)
CX3 = Kondensator (CM)
TH = Temperatursensor
MS1 = Mikroschalter (Tank voll)
MS2 = Mikroschalter (Pumpe)
Farbkennzeichnung
Y
= Gelb
W = Weiß
R = Rot
BU = Blau
BR = Braun
BK = Schwarz
GR = Grau
OR = Orange
13
