Shelf 02 Re:sound G/S
9
Positioning the loudspeakers
Your speakers are set up correctly, if
your favourite listening position and
the speakers
form an approximately
equilateral triangle. The speakers
should radiate from an acoustically
hard environment with good
reverberation characteristics into the
more damped part of the listening
area.
The Re:sound shelf have been
especially designed for standing on
a bookshelf or sideboard.
Figure: speaker on a bookshelf
The sound radiation is not to be
impeded; no object whatsoever
should be placed in front of or too
near to the speakers. The listener
should see both speakers
completely.
Please make sure that you do not
put your books too close to the
Re:sound shelf (fig. left) since part
of the sound comes out of the bass-
reflex openings on the backside of
your speakers. Therefore, we
recommend to leave about one
inch of space on the left or the right
side of the unit as well as behind it.
For best sound quality, position the
speakers at ear level (± 12 in. / ± 30
cm).
Please note that positioning the
speakers opposite to large and
smooth walls can cause
unpleasant reflections.
The low frequency behavior may be
controlled by the distance of the
speakers to the walls. According to
the acoustic actualities of your
room very serious changes of the
bass volume can occur between
the possibilities ‘’larger distance”
(slim bass) and ‘’in the angle of the
room” (beefy bass)’’.
DUDEN
A
DUDEN
B
2,5 cm
1 in.
