10
Connecting the loudspeakers
Important
Before cabling disconnect your hi-
fi system (amplifier, receiver,
power amplifier etc.) from the
mains !
Connect the loudspeaker outputs A
or B on the back of your amplifier to
the corresponding terminal screws
on the speakers, using loudspeaker
cables with bared ends. Watch the
polarity: connect the positive pole
of your amplifier to the positive pole
of your Ioudspeaker.
Cable Length & Cross Section
Revox loudspeakers have
consistent electrical phase and
impedance characteristics and are
an uncritical load for the power
amplifier and the loudspeaker
cables.
Your specialist dealer offers
loudspeaker cables in diverse
styles and with various cross
sections. He will be glad to advise
you according to your individual
needs.
In order to keep cable loss as low
as possible, we suggest the
following cable cross section
dimensioning scheme:
Cable length Dimension
up to 5m / 16ft: 1.5 mm 2 / AWG15
up to 10m / 33ft: 2.5 mm 2 / AWG13
over 10m / 33ft: 4.0 mm 2 / AWG11
We advise against using long
cables (more than 20 m / 65 feet)
because of inevitable loss.
