CONTROL ELEMENTS
1. LED Display
2. IR Receiver for the Remote Control
3. Power button
4. Power LED
5. Signal LED
6. USB Port A (behind the flap)
7. CI / CI+ Slot (behind the flap)
Description of the elements:
1.
Aerial Input (13V/18V, max. 300mA)
2. USB Port B
3. SCART output TV
4. Power Cord
5. Power On/Off
6. Loop Out Aerial output
7. FBAS video output (CVBS)
8. Stereo audio output (L/R)
9. HDMI Output
10. Digital audio output (coaxial)
Note:
Make sure when installing the antenna cable that the device is disconnected from the power.
Front Panel
Rear Panel
