Ernesto 78580/III - Handbuch (Seite 5)

6 GB
Kitchen Mixer Tap
Introduction
Dear Customer, you have purchased a durable
high quality product manufactured by us. Before
installation please read through the whole of these
instructions and take note of the advice they contain
before you start the installation. These instructions
contain important information about installation,
settings and care. Keep these instructions safe and
if you pass on the product to anyone else please
pass on the documentation as well.
Proper use
This product is suitable for instantaneous water
heaters (flow heaters) and boilers. It is not suitable
for low pressure water heaters such as wood or
coal burning bath geysers, oil or gas bath geysers,
open electrically heated water tanks. Any use other
than that described here or modification to the prod-
uct is not permitted and may lead to damage to
persons or property. There is also the risk of injury
and loss of life. The product is intended for personal
use only and not for medical or commercial use.
Components, fittings
and fixings (Fig. A)
1 Changeover button for spray
2 Lever
3 Lock screw
4 Hot / cold label
5 Cartridge end ring
6 Cartridge locking ring
7 Adjusting ring
8 Cartridge
9 Sealing ring
10 Seal
11 Metal washer
12 Threaded sleeve
13 Ring nut
14 Locking screws
15 Hose tails / Connection pipes
16 Ring nut
17 Allen key
18 Fastening screw (swivel arm)
19 Sealing ring (spray head)
20 Mixer nozzle
20 a Sealing ring
20 b Insert
20 c Mixer nozzle bushing
21 a Hot water connection
21 b Cold water connection
Technical Data
Connections: 3 /
8
" IG
Union nut for the
water connection: 19 mm
Water temperature: max.: 85 °C
Water pressure:
min.: 0.5 bar,
max.: 3 bar
Safety advice
DANGER OF LOSS OF LIFE
AND ACCIDENT TO INFANTS
AND CHILDREN!
Never leave
children unsupervised with the packaging
materials. Danger of suffocation.
CAUTION! DANGER OF INJURY! Please
ensure that no parts are damaged and that all
parts are correctly assembled. Incorrect assem-
bly or fitting may lead to injury. Damaged parts
can adversely affect safety and proper function.
CAUTION - RISK OF DAMAGE! Please
have the installation done by experienced per-
sons only.
Ensure that all seals are correctly seated.
DANGER OF SCALDING! When making
the hot water setting please ensure that the
temperature of the water is not too high.
Please note that seals are wear parts and
therefore will require to be replaced from time
to time.
Introduction / Safety advice
