Ernesto 78580/III - Handbuch (Seite 7)

8 GB
Setting the scald protection
(Fig. C)
The cartridge 8 in this faucet has a scald protection
function. This function is not activated before leaving
the factory (neutral setting).
CAUTION!
Do not alter the setting of the scald
protection until you have installed the faucet.
Switch off the general water supply.
1. Remove the red / blue hot / cold plate 4 by
moving the handle 2 into top-most position
and pushing the plate out carefully from inside
with a long, flat object.
2. Release the locking screw 3 with the Allen
key 17 by turning it in an anticlockwise direction.
CAUTION! Do not take the screw completely
out; just loosen it until the lever
2 can be easily
taken off.
3. Take off the lever 2 .
4. Unscrew the cartridge end ring 5 . Now take
off the black adjusting ring 7 .
Note: Set the cartridge pin horizontally. This
makes it easier to take off the adjusting ring 7 .
Do not use pliers. Do not release the cartridge
nut and do not take off the cartridge
8 .
5. To reduce the flow of hot water:
Put the adjusting ring 7 back on in the offset
position, as shown in Figure C/1.
To restrict the flow of hot water
completely:
Put the adjusting ring
7 on, as shown in
Figure C/2.
To deactivate the restriction of the
flow of hot water:
Put the adjusting ring
7 on in the neutral position,
as shown in Figure C/3.
6. After setting the scalding protection, replace
the cartridge end ring 5 and lever 2 .
Servicing and cleaning
Maintaining and cleaning
the faucet
Please note that sanitary fittings require special care.
Please observe the following instructions:
Do not use any type of lime removal agent, acidic
cleaners or scouring agents. Never use corrosive
or alcohol-based materials for cleaning.
Dry your taps with a cloth after every use in
order to avoid the build-up of any limescale.
Clean your fittings with clean water, mild deter-
gent and a soft cloth or leather only.
Unscrew the mixing nozzle 20 at regular intervals
and remove any limescale deposits or foreign
bodies. If it is very dirty or damaged, replace
the mixing nozzle
20 with a new one, which you
can order through the service centre indicated.
Note:
Use a 23 mm spanner to unscrew the
mixer nozzle 20
then wrap the mixer nozzle
20 in a damp, thin cloth, so that it is not dam-
aged. A pipe wrench with plastic jaws is also
suitable. In any event, make sure that you do
not damage the mixing nozzle
20 .
CAUTION! When you attach the mixer nozzle
20 , make sure that the sealing ring 20 a is rein-
serted correctly.
The fastening screw 18 on the swivel arm holds
the swivel arm in its horizontal position. There-
fore the fastening screw
18 is not suitable for
holding the swivel arm in its rotational position.
If the care and maintenance instructions are not fol-
lowed, damage to the surface of the fitting can be
expected. Claims under the warranty are excluded
in this case.
Replacing the cartridge
The cartridge 8 is a wear part and must be
replaced at least every 2 years. If this is not done,
it could result in malfunctions and leaks. A new
cartridge
8 can be obtained from the service
centre indicated below.
Proceed as follows to replace the cartridge 8 :
1. Shut the main water supply off.
Allow the remaining water to run off.
2. Remove the hot/cold plate 4 and unscrew
the locking screw 3 with the Allen key 17 in
an anticlockwise direction.
3. Pull the handle 2 upwards and off.
Use / Servicing and cleaning
