Ernesto 78570 / II - Handbuch (Seite 8)

9 GB/IE
Servicing and cleaning / Disposal / Information
© Servicing and cleaning
© Maintaining and cleaning the
faucet
Please note that sanitary fittings require special care.
Please observe the following instructions:
˽
Dry your taps with a cloth after every use in
order to avoid the build-up of any limescale.
˽
Clean your fittings with clean water, mild deter-
gent and a soft cloth or leather only.
˽
Do not use any agents to remove limescale,
acidic cleaning agents or scouring agents of
any kind. Do not use corrosive or alcohol-
con-taining agents for cleaning (including for
coloured surfaces).
˽
Dry your taps with a cloth after every use in or-
der to avoid the build-up of any limescale.
˽
Unscrew the mixing nozzle 23 at regular inter-
vals and remove any limescale deposits or for-
eign bodies. If it is very dirty or damaged, re-
place the mixing nozzle
23 with a new one,
which you can order through the service centre
indicated.
Note:
The mixing nozzle 23 can normally be
unscrewed by hand. Otherwise you can use a
23 mm wrench and you must lay a thin, damp
cloth around the mixing nozzle
23 so that you
do not damage it. A pipe wrench with plastic
jaws is also suitable. In any event, make sure
that you do not damage the mixing nozzle
23 .
If the care and maintenance instructions are not fol-
lowed, damage to the surface of the fitting can be
expected. Claims under the warranty are excluded
in this case.
© Replacing the cartridge
A cartridge 7 is a wear part that needs replacing
according to the hardness and / or degree of
contamination of the water. This becomes evident
when the handle
1 becomes difficult to move.
New cartridges can be obtained from the listed
service office.
Proceed as follows to replace the cartridge 7 :
1. Shut the main water supply off.
Allow the remaining water to run off.
2. Remove the hot/cold plate 3 and unscrew
the locking screw 2 with the Allen key 29 in
an anticlockwise direction.
3. Pull the handle 1 upwards and off.
4. Unscrew the cartridge cover ring 4 .
5. Release the cartridge securing ring 5 beneath
it and pull the complete cartridge 7 out of the
body of the faucet.
6. Place the new cartridge into the body of the fau-
cet in exactly the same way. Make sure that the
seal is fitted properly under the cartridge. Make
sure that the guides are in the corresponding
holes.
7. Replace all aforementioned parts. Tighten the
cartridge securing ring 5 hand-tight whilst
holding the faucet in place against the rotating
movement. This ensures tightness and prevents
the lever motion from becoming sluggish.
© Disposal
To protect it from any damage in transit, this product
is delivered in secure packaging. The packaging
consists of recyclable materials. Please dispose of
them in an environmentally friendly way.
Do not throw the product away with normal domestic
waste at the end of its useful life; instead, please
contact your local authority to find out how you can
dispose of items in an environmentally friendly way.
© Information
© Potability of mains water
˽
Find out about the potability of your mains water
supply. Your local water authority or water sup-
ply company will be able to inform you.
