SPL Control One Monitor Controller Benutzerhandbuch
Seite 2

2
Control One
Read the security advices on page 6!
Read the installation instructions of the included external
power supply on page 8.
Make sure that the Power switch on the rear is set to Off
(Off = out position / ON = in position).
Connect the included power supply to the DC input and
an appropriate mains socket outlet.
Connect your speakers to the Speaker Outputs.
You can connect two pairs of active stereo speakers – A and B. The A
Speaker Output has a dedicated Sub Output for an active subwoofer.
Connect your headphone to the headphone output.
Connect your analog sources to the Line Inputs.
Connect the Line Out to your analog audio device.
The Line Out plays back the signal from Line Input 1, Line Input 2 or
Line Input 1 and 2 summed – depending on the Line input switch.
The level is unity gain, thus independent of the volume control.
Set the dip switch to your needs.
Dip switch 1 on/down = attenuate the speaker outputs by 10 dB.
Dip switch 2 = n.c. (not connected).
Turn down speaker and headphone volume.
Switch the on Control One by pressing the Power button.
Choose speaker output A or B.
Select a monitoring mode: stereo, mono or L/R swapped.
Set the volumes and the crossfeed to taste.
Playback your music from the Line Inputs.
For playback switch between the Line Input 1, 2 or the
sum of Line Input 1 and 2.
Have fun!
More information: SeriesOne.spl.audio
17
