4 Control One
Analog inputs & outputs; 6.35 mm (1/4") TRS Jack (balanced), RCA
Input gain (max.) +22.5 dBu
Line Input 1 (balanced): Input impedance 20 kΩ
Line Input 1: Common mode rejection < 60 dB
Line Input 2 (unbalanced): Input impedance 10 kΩ
Output gain (max.): Speaker Outputs (600 Ω) +22 dBu
Line Output (unbalanced): Output impedance 75 Ω
Speaker Output 1 (balanced): Output impedance 150 Ω
Sub Output low filter none (full range)
Sub Output (balanced): Output impedance 150 Ω
Speaker Output 2 (unbalanced): Output impedance 75 Ω
Frequency range (-3dB) 10 Hz - 200 kHz
Dynamic range 121 dB
Noise (A-weighted, 600 Ω load) -99 dBu
Total harmonic distortion (0 dBu, 10 Hz – 22 kHz) 0.002 %
Crosstalk (1 kHz) < 75 dB
Fade-out attenuation -93 dB
Headphones Output; 6.35 mm (1/4") TRS Jack
Wiring
Tip = Left, Ring = Right,
Sleeve = GND
Source impedance 20 Ω
Frequency range (-3 dB) 10 Hz - 200 kHz
Noise (A-weighted, 600 Ω) -97 dBu
THD + N (0 dBu, 10 Hz – 22 kHz, 600 Ω) 0,002 %
THD + N (0 dBu, 10 Hz – 22 kHz, 32 Ω) 0,013 %
Max output power (600 Ω) 2 x 190 mW
Max output power (250 Ω) 2 x 330 mW
Max output power (47 Ω) 2 x 400 mW
Fade-out attenuation (600 Ω) -99 dB
Crosstalk (1 kHz, 600 Ω) -75 dB
Dynamic range 117 dB
Specifications
