- 11 -
Video 60 Plus Studio Manual
access the bottom of the head.
The Video 60 Plus Studio can be mounted onto flat base
tripods and pedestals with 4 bolt flat base directly. For
Quickfix mount and all Sachtler pedestals the Multi Disc
from the Sachtler accessory range is required.
It is mounted onto the fluid heads 4 bolt flat base.
5.4 Conversion of the Video 60 Plus Studio to include half
ball
Put the Video 60 Plus Studio upside down, so that you
can access the bottom of the head.
Take at hand the ball adapter piece with clamping screw
from the Sachtler accessory range.
Place the adapter piece into the recess at the bottom side
of the head.
Fasten hand-tight the 4 allen screws.
The fluid head is tightened onto the tripod via the clam-
ping screw.
5.5 Conversion of the Video 60 Plus Studio to include
Mitchell
Especially in the United States the Mitchell mount is wide-
ly spread.
To convert put the fluid head upside down, so that you
can access the bottom of the head.
Take the Mitchell adapter piece with locking knob from the
Sachtler accessory range.
Place the adapter piece into the recess at the bottom side
of the head.
The fluid head is tightened onto the tripod via the Mitchell
locking knob.
