10. RFS 2.2 TRANSCEIVER AS RECEIVER
With broncolor power packs, monolights and lamps from other manufacturers,
which are not equipped to receive
RFS 2
data, the unit can be used as an ex-
ternal receiver.
The unit will not be automatically switched to receive when connected to a
power pack or monolight.
To switch from transmit mode to receive mode, or vice versa, please proceed
as follows:
1) Hold the "test" key pressed and simultaneously switch the unit on
2) Press the "
LP
" key and use the scrolling wheel to change to receive or
transmit as appropriate
3) Press the "
LP
" key again to confirm the selection, and switch the unit off
When it is switched on again, the switchover will have been completed.
In receiver mode, the
PC
port will be automatically configured as an output.
Connect the sync cable to the "out" socket of the
RFS 2.2
transceiver and to
the sync connection on the flash unit.
