13
Motor
Drive Belt / DC Motor
Speed settings 33/45
Wow & Flutter < ±0,12 % (DIN WTD)
Tonearm
Function Fully automatic or manually operated
Bearing Ball-bearing
Effective length 221,5 mm
Offset Angle 25,6°
Overhang 19 mm
Type statically balanced, fixed setting
Stylus Pressure Range 1,8 g +/- 0,3 g
Factory installed Pick-up Audio-Technica AT91
Replacement Stylus Audio-Technica ATN91
Platter
Material Aluminium Die-cast
Mat Rubber 2,5 mm
Bearing Hardened Steel Spindle, Brass Bushing
Diameter 296 mm
Weight incl. Mat 667 g
Plinth
Surface Finish Plastic / MDF Construction
Feet Ø 62 mm / Elastomer Damping Element
Connection RCA cable, fixed
Connection to Phono Input YES
Connection to Line Input YES
Digital Output X
Dimension (closed dust cover) 435 x 372 x 132 mm
Dimension (open dust cover) T: 405 mm / H: 390 mm
Weight 5 kg
Power Supply
The efficiency readings were taken with an input Voltage
of 230 V AC at 50 Hz
Type FJ-SW 1261200500DN
Input Voltage 100 (-10 %) V AC to 240 (+10 %) V AC
Frequency 50 / 60 Hz
Output Voltage 12 V DC
Output Current 0,5 A
Output Watt 6 W
Average Efficiency During Operation ≥ 78.88%
Power Consumption at Idle < 0,1 W
Technical Specifications
