Fronius DATCOM cabling Benutzerhandbuch
Seite 4
EN
System limits:
Maximum cable lengths in one system:
-
1000 m when using terminating plugs
-
1000 m between two components in the case of systems
without terminating plugs (see section entitled “Forming a
ring using a cable”)
Fronius Datalogger Web system overview
Components
Shielding
Cabling
(e.g. T568B)
Terminating plug*
Fronius Datalogger
Web
Cable 1:1 at least CAT 5
twisted pair and shielded
e.g. S/STP
Fonius inverter with
Fronius Com Card
IN OUT
IN OUT
*
*
max. 1000 m
Terminating plug*
Continuous shielding
1
+12 V
2
GND
3
RX+
4
TX+
5
TX-
6
RX-
7
GND
8
+12 V
1
+12 V
2
GND
3
TX+
4
RX+
5
RX-
6
TX-
7
GND
8
+12 V
1
+12 V
2
GND
3
TX+
4
RX+
5
RX-
6
TX-
7
GND
8
+12 V
1
+12 V
2
GND
3
RX+
4
TX+
5
TX-
6
RX-
7
GND
8
+12 V
IN
OUT
IN
OUT
Fronius Datamanager system overview
OUT IN
*
max. 1000 m
IN
Components
Cable 1:1 at least CAT 5
twisted pair and shielded
e.g. S/STP
Fonius inverter with
Fronius Com Card
Terminating plug*
Fronius inverter with Fronius
Datamanager
Shielding
Continuous shielding
IN
IN
OUT
Cabling
(e.g. T568B)
Terminating plug
integrated
1
+12 V
2
GND
3
TX+
4
RX+
5
RX-
6
TX-
7
GND
8
+12 V
1
+12 V
2
GND
3
RX+
4
TX+
5
TX-
6
RX-
7
GND
8
+12 V
1
+12 V
2
GND
3
TX+
4
RX+
5
RX-
6
TX-
7
GND
8
+12 V
Number of components per monitoring system (per Fronius
Datalogger):
-
100 inverters
-
10 Fronius Sensor Card / Box
-
10 Fronius Public Display Card / Box
