5 FBGK 24.5 A1
GB
CY
Assembly
Step 1
♦ Take all of the parts of the barbecue from the zipped compartment of the
transport bag
7 and remove all packaging material. Choose a suitable
fi rm and level surface to assemble the barbecue.
Step 2
♦ Turn over the fi re pan 4 so its open side is facing downwards and insert
the feet 5 into the holes provided for this purpose on the underside of the
fi re pan 4 .
♦ In order to insert the brackets of the feet 5 into the holes in the fi re pan 4 ,
push the ends together a little (see Fig. 1).
♦ Ensure that the bracket guide A is beneath the tab B .
This is the only way to ensure that the barbecue has the required stability.
Fig. 1
Step 3
♦ Turn the barbecue over and place it on a sturdy, level and fi reproof surface.
B A
5
4
