8 GB
Preparing the product for use / Maintenance and cleaning / Disposal Preparation / Before installation / Installation / Preparing the product for use
- Drill (ø approx. 0.6 cm)
- Edge cutter
- Ladder
Before installation
Important: The electrical connection must be
carried out by a qualified electrician or someone
trained to perform electrical installations. This person
must be familiar with the features of the light and
the connection requirements.
Familiarise yourself with all instructions and
diagrams in this manual as well as with the
light before installation.
Before installation, ensure that the cable that
the light is to be attached to is not live. Remove
its fuse or switch off the automatic cutout in the
fuse box (0 position).
Use the voltage tester to check that there is no
voltage.
Installation
Fitting the light
Remove the screws 2 visible on the side of the
terminal housing 6 and take the installation
frame 1 on the back off (see diagram).
Mark the boreholes using the slotted holes pro-
vided for the screws in the installation frame
1 .
Now drill the screw holes (approx. 6 mm, depth
approx. 40 mm). Ensure that the feed cable is
not damaged.
Insert the dowels into the drilled holes. Fasten
the mounting bracket
1 in place with the
supplied screws.
Connect the supply cable via lustre terminal 4 .
Ensure that the cables have been connected in
line with the correct colour coding.
Now connect the earthed conductor (green-
yellow) to the earth terminal labelled in the
terminal housing
6 (see diagram).
Screw the light onto the installation frame 1
using the screws 2 .
Place the lamp glass 10 carefully over the
fitting 9 and fasten it in place by tightening the
threaded ring 11 using the supplied tool 12 .
Use a clean, fluff-free cloth when you are
replacing a bulb
13 .
Rotate the bulb 13 carefully clockwise into
the fitting.
Check that the bulb is correctly seated.
Your light is now ready for operation.
Preparing the product for use
Inserting / replacing batteries
Release the screw from the battery compartment
of the remote control handset
8 (rear side) by
unscrewing it with a crosshead screwdriver in the
direction.
Remove the used battery, if present.
Insert a new battery into the battery compartment.
Use batteries type A23, 12 V only.
Note: Make sure you fit the battery the right
way round (polarity). The correct polarity is
shown inside the battery compartment.
Close the battery compartment of the remote
control handset
8 (rear side) by screwing the
screw in with a Phillips screwdriver in the
direction.
Switching the light on / off
You have the choice of operating the light from an
ordinary wall switch or switching it on and off using
the supplied remote control unit.
Switching the light on / off using the
remote control handset:
– The wall switch is in the normal position (OFF).
Press the wall switch (ON).
Press the ON button of the remote control
handset
8 to switch on the light.
