8 GB/IE
Q
 Preparing the product for use
Q  assembling the lamp
note: You will require a second person to help
with the assembly of the product.
note: Assembly is identical for both models
(1241/022L or 1242/022L).
j
First screw the support tube 19 clockwise into
the upper support tube 22 . Ensure that the
mains lead does not become trapped when it
is fed through the support tubes
19 , 22 .
j
Then screw the support tube 10 clockwise into
the flexible arm 5 .
j
Screw the two threaded rods 18 clockwise into
the support tubes 10 , 19 and push the support
tube mount 17 on to the threaded rods 18 .
j
Insert the floor lamp with the threaded rods 18
into the preformed holes in the base 13 .
j
Place the plain washers 14 and then the serrat-
ed lock washers 15 from the underside of the
base 13 on to the threaded rods 18 . Using the
open spanner, tighten the nuts 16 clockwise on
to the threaded rods 18 to fix the floor lamp to
the base 13 .
note: Ensure that you hold the support tubes
10 , 19 and threaded rods 18 firmly in place
when you are tightening the nuts 16 .
j   Push the lamp glasses 3 , 7 over the fittings
4 , 6 . Fix the lamp glasses in place with the
threaded rings 2 , 8 using the tool 9 .
note: Use a dry, fluff-free cloth for inserting
the bulbs.
j   Screw the bulbs 1 , 11 clockwise into the
fittings 4 , 6 .
j   Insert the mains plug 12 into a properly
installed socket.
Your lamp is now ready for operation.
Q  Switching the lamp on/off
j   Use the ON/OFF switch 21 to switch the
uplight on or off.
j
Use the ON/OFF switch 20 to switch the read-
ing lamp on or off.
Q  Directing the lamp
j
Bend the flexible arm 5 to bring the reading
lamp into the desired position.
Q
Replacing a bulb
WaRnIng!
RISk oF ELECTRIC SHoCk!
First pull the mains plug 12 out of the mains socket.
CauTIon! RISk oF buRnS! First allow the
lamp to cool completely.
j
Unscrew the defective bulb 1 , 11 anticlock-
wise out of the fitting 4 , 6 .
j
Then screw a new bulb clockwise into the fitting.
note: Use only 230 - 240 volt ~ energy-saving
bulbs with an E14 fitting and a maximum power
output of 9 watts for the reading lamp.
Use only 230 - 240 volt ~ energy-saving bulbs
with an E27 fitting and a maximum power out-
put of 22 watts for the uplight.
or
Use only 230 - 240 volt ~ bulbs with an E14
fitting and a maximum power output of 25 watts
for the reading lamp. Use only 230 - 240 volt ~
bulbs with an E27 fitting and a maximum power
output of 60 watts for the uplight.
Q  Care and cleaning
WaRnIng!
RISk oF ELECTRIC SHoCk!
First pull the mains plug 12 out of the mains socket.
CauTIon! RISk oF buRnS! First allow the
lamp to cool completely.
WaRnIng!
RISk oF ELECTRIC SHoCk!
For electrical safety reasons, never clean the lamp
with water or other fluids nor immerse it in water.
j   Always use a dry, fluff-free cloth for cleaning.
j Do not use any solvents, petrol or similar. This
would cause damage to the light.
Preparing the product for use / Care and cleaning
