14 GB/IE/CY
14 GB/IE/CY
the substrate surface later
(see Fig. G).
3. Switch the light on by
pressing the ON / OFF
switch
9
.
Note: Please bear in mind
that the light will only switch
itself on or off under twilight
conditions automatically if
the light is switched on.
4. Insert the light into the
substrate.
Your light is now ready for
operation.
Installing the floor
light in concrete
substrates
Note: A quantity of mixed
concrete is required for this
stage of the installation. Follow
the manufacturer’s instructions.
1. Choose a suitable location
for the floor light.
2. Drill a hole in the concrete
substrate.
Note: Ensure
that the depth of the hole
corresponds with the depth
of the floor insert
11
with
concrete socket including
the floor light. Bear in
mind that the decorative
collar
2
must be placed
