Placement
For best results, place your Solar lamp in a
location where sunlight shines directly onto the
collector panel 4. Direct sunlight of at least 8
hours is ideal to ensure that the battery is fully
charged. The location must be free from shadow
and shade. Make sure that the collector panel
4 is not subjected to light sources other than
sunlight. Otherwise, the lamp will not be swit-
ched on at twilight.
Initial use
³ Remove the collector panel 4 together with
the reflector 5 out of the housing 6.
Turn the reflector 5 somewhat against the col-
lector panel 4, until it releases itself from the re-
straint.
³ Remove the reflector 5 from the collector pa-
nel 4.
³ Place the function switch 1, on the bottom of
the collector panel 4, at the ON position.
³ Place the reflector 5 and the collector panel
4 back together again.
³ Replace the collector panel 4, together with
the reflector 5, back into the housing 6.
³ Place the solar lamp at a suitable location.
Note:
The charging process will only start if the functi-
on switch 1 is in the ON position. It can take a
few days until the Solar Lamp has reached its
optimal performance efficiency.
After the battery is charged, the solar light turns
itself on automatically at dusk.
³ To switch the solar lamp off, place the functi-
on switch 1, on the bottom of the collector
panel 4, into the OFF position.
Changing the battery
Replace the battery when the illumination time,
despite a day-long charge period, diminishes af-
ter 2 hours of darkness.
³ Remove the collector panel 4 together with
the reflector 5 out of the housing 6.
Turn the reflector 5 somewhat against the col-
lector panel 4, until it releases itself from the re-
straint.
³ Remove the reflector 5 from the collector pa-
nel 4.
³ Open the battery compartment 3 on the un-
derside of the collector panel 4.
³ Remove the battery and replace it with a new
one of the same type. When inserting it, com-
ply with the polarities.
³ Close the battery compartment 3 and repla-
ce the reflector 5 and the collector panel 4
back together.
³ Replace the collector panel 4, together with
the reflector 5, back into the housing 6.
Cleaning
Clean the collector panel 4 with a moist cloth.
Clean the housing 6 of the solar light with a
soft brush.
Attention!
• Do not use aggressive or chemical cleaning
agents. These could cause damage to the
appliance.
