6 GB/IE
Installation / Maintenance and cleaning / Service
Mark the positions for the drilled holes on the
ceiling using the predrilled holes in the mounting
bracket as a guide.
Now drill the fixing holes.
CAUTION! Ensure that you do not damage
any cables in the ceiling.
Insert the dowels 1 into the drilled holes.
Fix the mounting bracket to the ceiling with the
screws 4 .
Now connect the connection cable of the light
to the mains connection cable (external) 6 by
means of the terminal block 5 .
Note: Ensure that each wire of the mains
connection cable (external) is properly con-
nected in the correct place: live wire, black or
brown = symbol L, neutral wire, blue = symbol N,
protective earth wire, green-yellow = symbol .
Fix the light to the mounting bracket with the
screws.
Unscrew the screws 11 of the lamp fittings 10 .
Insert the energy-saving bulbs 7 and place
the lamp glasses 8 on the fittings. Tighten the
screws again.
Note: Use a clean, fluff-free cloth when you
are inserting a bulb.
Your light is now ready for operation.
Directing the lamps
CAUTION! RISK OF BURNS! Change the
orientation of the lamp glasses 8 only when the
lamp has been switched off and the lamp head has
completely cooled down.
Turn the individual lamp glasses in the desired di-
rection.
Note: The lamp glasses can be turned
through approx. 330°.
Tilt the individual lamp glasses to the desired
angle.
Note: The lamp glasses can be tilted through
approx. 90°.
Maintenance and cleaning
DANGER TO LIFE BY ELEC-
TRIC SHOCK! Before carrying out any work on
the light, switch the electricity supply off at the fuse
box or remove the screw-in fuses from the fuse box.
DANGER TO LIFE BY ELEC-
TRIC SHOCK! For electrical safety the light must
never be cleaned with water or other liquids, or
immersed in water.
Replacing a bulb
DANGER TO LIFE BY ELEC-
TRIC SHOCK! Before carrying out any work on
the light, switch the electricity supply off at the fuse
box or remove the screw-in fuses from the fuse box.
CAUTION! RISK OF BURNS! Allow the
light to cool down completely.
Note: Use a clean, fluff-free cloth when you are
replacing a bulb.
Use 230 V∼ energy-saving bulbs with an E14
fitting and a maximum power of 9 watt only.
Replace the bulbs in accordance with Figs. A
and B.
Cleaning
CAUTION! RISK OF BURNS! Allow the
light to cool down completely.
Do not use solvents, petrol etc.
Use a dry fluff-free cloth when you are cleaning.
Service
GB
Service Great Britain
Tel.:
0871 5000 720 (0,10 GBP/Min.)
e-mail: [email protected]
IAN 66143
