3 GB/IE
Introduction / Safety advice
Night stand
Q Introduction
Before assembling and using the product for the first time, take
time to familiarise yourself with the product first. Read the following
assembly instructions and safety instructions carefully. Only use
the product as described and for the designated areas of application. Please
keep these instructions in a safe place. If you hand this product on to a third
party, you must also pass on all documents relating to the product.
Q Intended Use
This article is designed for the storage of small and light objects at home. Any
use other than previously mentioned or any product modification is prohibited
and can lead to injuries and / or product damage. The manufacturer is not
liable for any damages caused by any use other than for the intended purpose.
The product is not intended for commercial use.
Q Description of parts and features
1 Top
2 Side panel 1
3 Side panel 2
4 Strut
5 Rear panel
6 Rear panel of drawer
7 Side panel 1 of drawer
8 Side panel 2 of drawer
9 Bottom of drawer
10 Front panel of drawer
11 Base plate
12 Screw (approx. ø 5 x 35 mm)
13 Wooden dowel (approx. ø 6 x 30 mm)
14 Screw-in dowel (approx. ø 6 x 25 mm)
15 Screw (approx. ø 5 x 11 mm)
16 Drawer rail
17 Screw (approx. ø 4 x 12 mm)
18 Screw-in dowel (approx. ø 6 x 39 mm)
19 Foot
20 Eccentric connector (approx. 10 x 10 mm, ø x H)
21 Fastening element
22 Screw (approx. ø 3 x 12 mm)
23 Screw hook (approx. ø 6 x 50 mm)
24 Dowel
25 Eccentric connector (approx. 15 x 12 mm, ø x H)
26 Cover cap
27 Screw (approx. ø 7 x 50 mm)
28 Screw (approx. ø 4 x 25 mm)
29 Allen key
Q Technical data
Dimensions: approx. 50 x 44 x 39 cm (w x h x d)
Material: Chipboard with coating of melamine film
Max. load capacity: 30 kg
Q Supply Scope
Note: Take care when unpacking that you do not inadvertently throw away
any assembly material.
Immediately after unpacking, check that the delivery is complete and that the
product and all its parts are in perfect condition. Do not under any circumstances
assemble the product if the delivery is incomplete.
1 Top
1 Side panel 1
1 Side panel 2
2 Struts
1 Rear panel
2 Rear panels of drawer
2 Side panels 1 of drawer
2 Side panels 2 of drawer
2 Bottoms of drawer
2 Front panels of drawer
1 Base plate
8 Screws (approx. ø 5 x 35 mm)
16 Wooden dowels (approx. ø 6 x 30 mm)
8 Screw-in dowels (approx. ø 6 x 25 mm)
8 Screws (approx. ø 5 x 11 mm)
4 Drawer rails
4 Screws (approx. ø 4 x 12 mm)
4 Screw-in dowels (approx. ø 6 x 39 mm)
4 Feet
8 Eccentric connector (approx. 10 x 10 mm, ø x H)
2 Fastening elements
2 Screws (approx. ø 3 x 12 mm)
1 Screw hook (approx. ø 6 x 50 mm)
1 Dowel
4 Eccentric connectors (approx. 15 x 12 mm, ø x H)
8 Cover caps
4 Screws (approx. ø 7 x 50 mm)
4 Screws (approx. ø 4 x 25 mm)
1 Allen key
1 Assembly instructions
Safety advice
Keep all the safety advice and instructions in a safe place
for future reference!
m To avoid the risk of injury!
J WarNINg! DaNgEr OF LOSS OF LIFE aND
aCCIDENT TO INFaNTS aND CHILDrEN! Never leave
children unsupervised with the packaging materials. Danger
of suffocation. Keep out of the reach of children. It is not a toy.
WarNINg! rISK OF FaTaL INJUrY! During installation keep
children away from the area in which you are working. The scope of
supply includes a number of screws and other small parts. These may
prove life-threatening if swallowed or inhaled.
WarNINg! rISK OF FaTaL INJUrY! Please ensure that you
do not drill into any electrical wiring, gas or water pipes in the wall. If
necessary, carry out checks with a wire, pipe and stud detector before
you drill into a wall.
m CaUTION! DaNgEr OF INJUrY! Please ensure that no parts are
damaged and that all parts are correctly assembled. Incorrect assembly
or fitting may lead to injury. Damaged parts can adversely affect safety
and proper function.
m CaUTION! Do not leave children unsupervised. The product is not a
climbing frame or toy! Make sure that people, especially children, do not
climb onto or stand on the product. The product can become unstable
and tilt to the side and / or fall over. This could result in injuries and / or
damage.
J Make sure that the product is only assembled by competent persons.
J Make sure that this product is standing on a solid, level surface.
J Distribute weight upon this products‘ surface evenly so that it cannot
overturn.
J
30 kg
Never load more than 30 kg onto the product. Otherwise
there is a risk of injury and / or damage to the product.
J Regularly check the stability of all connections and retighten the screws.
m CaUTION! Do not lift or move the product if it is supporting any object.
