4 GB/IE
Safety advice / Assembly / Cleaning and Care / Disposal
How to prevent damage to property!
J
Before wall installation please ensure that the selected wall is suitable for
attaching the product. Ask in specialist shops if necessary.
J
Before installing the product on the wall you should find out about the
appropriate installation material for your wall. For wall installation we
have enclosed installation material that is suitable for standard masonry.
Q
assembly
Note: Assemble the product on an adequately large, scratch-proof surface.
If necessary place a cover down first to avoid damaging the product.
Note: You will require an electric drill and a Phillips screwdriver to assemble
the product.
Proceed as follows:
Figure a:
j
Insert the 4 wooden dowels
13
into the recesses in the top faces of the
sides
2
,
3
.
j
Insert a eccentric connector
25
into each of the 2 holes in each of the
sides
2
,
3
.
j
Fix the drawer rails
16
to the side panels
2
,
3
using two screws
15
each.
j
Insert a wooden dowel
13
into each of the 4 holes in each of the struts
4
.
Figure B:
j
Connect the sides
2
,
3
and the struts
4
as shown in the figure.
j
Connect the bottom
11
and sides
2
,
3
as shown in the figure.
j
Using the Allen key
29
, screw the 4 screws
27
into the predrilled holes
in the bottom
11
.
j
Attach the feet
19
with the screws
28
to the underside of the bottom
11
.
Figure C:
j
Slide the back
5
from above into the locating slots in the sides
2
,
3
.
j
Screw the 4 cam pins
18
into the predrilled holes in the top
1
.
j
Place the top
1
onto the side panels
2
,
3
.
j
Fix the elements by tightening the eccentric connectors
25
of the side
panels
2
,
3
clockwise.
Figure D:
j
Fix the fastening element
21
by means of a screw
22
.
Figure E:
j
Fix the drawer sides
7
,
8
to the drawer back
6
with the 4 screws
12
.
j
Insert the bottom of the drawer
9
.
j
Insert 2 eccentric connectors
20
into the pre-drilled holes of each side
panel
7
,
8
.
j
Screw 4 screw-in dowels
14
into the pre-drilled holes on the front panel
of drawer
10
.
j
Place the front panel of drawer
10
onto the side panels
7
,
8
.
j
Fix the elements by tightening the eccentric connectors
20
of the side
panels
7
,
8
clockwise.
j
Plug 4 cover caps
26
on the eccentric connectors
20
.
j
Insert the drawers. Make sure that the drawer rails
16
lie firmly in the
guide rails of the drawers.
j
Fix the drawer rails
16
from inside using 2 screws
17
.
j
Repeat the above steps for the other drawer.
Figure F:
Note: The bedside table has to stand firmly on the floor. Mount the night-
stand to the wall by use of screw hook
23
and dowel
24
.
j
Mark the position for the drilled hole on the wall (42 cm above the floor)
using a pencil.
WarNINg!
rISK OF FaTaL INJUrY! Please ensure that you
do not drill into any electrical wiring, gas or water pipes in the wall. If
necessary, carry out checks with a wire, pipe and stud detector before
you drill into a wall.
m CaUTION! DaNgEr OF INJUrY! Refer to the operating instructions
for your electric drill.
j
Drill the borehole using a 8 mm drill bit and insert the dowel
24
into the
borehole.
j
Screw the screw hook
23
into the dowel
24
. Make sure the hook ends
up facing upwards.
j
There is a pre-drilled hole on the rear side of the top
1
. Use it to hook
the bedside table onto the screw hook
23
.
Note: Regularly check the stability of all connections and retighten the
screws.
Q
Cleaning and Care
j
Clean the product with a dry, non-fluffing cloth.
j
To remove more stubborn dirt, use a damp cloth and, if necessary, a mild
cleaning agent.
j
Do not under any circumstances use corrosive or abrasive cleaning
agents. These may damage the product.
Q
Disposal
The packaging is made entirely of recyclable materials, which
you may dispose of at local recycling facilities.
Contact your local refuse disposal authority for more details of how to
dispose of your worn-out product.
Product description:
Night Stand
Model No.: Z29545
Version:
01 / 2011
