TAKE NOTE
► Do not touch the bulb with your bare fi ngers, use a lint-free soft cloth.
Fig. Changing the bulb
♦ Switch the appliance off with the On/Off switch 6 + 7 .
♦ Ensure that the mains power adapter resp. car adapter is not plugged into
the charging socket
12 .
♦ Loosen the retaining ring of the spotlight by turning it slightly clockwise
and then removing it from the appliance.
♦ Remove the cable and the retaining clip from the bracket .
♦ Remove the bulb from its socket and carefully loosen the plug connector
of the connecting cable.
♦ Insert a new bulb of the same type (see technical data) into the socket
and reattach the connection cable with the plug connector .
♦ Secure the bulb with the retaining clip and fasten them as per the cable
with the screw and the nut on the bracket .
♦ Replace the retaining ring of the spotlight on the appliance so that the
restraints of the ring engage and grip into the recesses of the housing. Lock
the retaining ring by turning it slightly anti-clockwise.
