Installation Manual - Solar-Log™ RS485 Wireless Package
2 Installation Manual - Solar-Log™ RS485
Wireless Package
2�1 Technical description
The Solar-Log™ RS485 Wireless Package connects the Solar-Log™ unit to the inverters wirelessly and is
often a practical alternative to modems and mobile data service packages.
2�2 Application example
Fig.: Application example for a wireless link
The RS485 wireless connection can be used to connect the inverters to the Solar-Log™ unit. It can also be
used to replace the wiring between the inverters.
Important !
Please note that the Wireless Module has to be pre-configured
for inverters from certain manufacturers.
