Height Adjustment of the Tonearm (VTA)
Depending on the pickup system used, it may
be necessary to adjust the Vertical Tracking
Angle (VTA). To do this, adjust the height of
the tonearm as follows:
At the base of the tonearm bearing there is a
conical adjustment ring , which is secured by
a lock nut above it. (Fig. 17) First loosen the
upper lock nut by turning it counterclockwise
with the special tool provided. Then you can
move the lower adjustment ring with the same
special tool : Turning it clockwise raises the
tonearm, turning it counterclockwise lowers it.
When you have set the correct tonearm height,
tighten the lock nut slightly while holding the
adjustment ring in place with your hand.
HEIGHT ADJUSTMENT OF THE TONEARM (VTA)
Fig. 17
