40 ELECTRICAL CONNECTIONS
Connections
Electrical Connections
The power supply of the TD 124 DD is realised
via the external power supply unit TPN 124.
First connect the supplied connection cable to
the output of the power supply unit, then to the
corresponding input on the rear of the TD 124
DD. (Fig. 20) For safe operation these connec-
tors should be locked with the locknuts.
WARNING: Before commissioning, make
sure that the mains voltage is correctly set
on the bottom of the power supply unit. Oth-
erwise there is a risk of damage to the unit.
(Fig. 21)
Only then connect the power supply unit to the
mains supply using the supplied mains cable .
Above the connection socket on the back of
the power supply unit is the mains switch with
which the power supply of the unit is switched
on and off. When the switch is in position 0, the
unit is completely disconnected from the power
supply.
Fig. 20 Fig. 21
