outdoor 80
6
Lining the speakers up
Here are a couple of tips for you
about lining the speakers up,
before you start the installation.
The speaker is designed such that
the best reproduction is achieved
when the tweeter is located above
the woofer. This is also true if the
speaker is mounted very high up,
underneath a roof overhang.
Both speakers must be lined up
the same way when they are
installed as a stereo pair.
Fig. 1
If circumstances do not permit the
speakers to be installed vertically,
they should be installed horizontally
as a mirror image of each other,
with the tweeters towards the
outside:
Fig. 2
The best results are achieved if the
tweeters are at about ear level or
when the tweeter is directed at
head height.
For that reason, if a high mounting
position is selected, we recommend
lining the speaker up vertically and
then tilting it downwards, as shown
in Fig. 3.
Fig. 3
The distance between the speakers
is dependent on the distance from
the listener. As a general rule of
thumb, the distance to the listening
position should be at least 2 m. The
distance between the speakers
should not be greater than the
distance to the listening position.
Important
Irrespective of how you
install or position the
speakers, you must always ensure
that they cannot fall down and
injure someone.
