4 GB/IE
®
Assembly / Cleaning /Disposal
Q
assembling the marquee
1. Remove the marquee with the folding frame
1
carefully from the storage
bag.
2. Pull the telescopic feet
10
out of the telescopic legs
6
until the locking
pin (telescopic leg)
9
clicks in place. (Fig. A)
3. Stand the marquee with the folding frame
1
upright on the ground.
(Fig. B)
4. Pull the folding frame apart evenly on opposite telescopic legs
6
. (Fig. C)
note: do not over-extend the folding frame!
5. Push the sliding clips
7
in each corner up until the locking pin (folding
frame)
8
clicks in place. (Fig. D)
6. Attach the corner canopies
12
by hanging the metal pin
13
in the
corresponding opening in the telescopic leg
10
.
7. Anchor the telescopic feet
10
in the ground with a peg
5
using the
opening in the foot plate
11
.
note: make sure that the pegs
5
are secure.
8. Tie the ropes
2
onto the loops
14
and pull them taut with pegs
5
in the ground. (Fig. E)
note: here also make sure that the pegs
5
are secure.
9. Suspend the side wall with the window
3
using the hook and loop straps
16
at the top from the framework (folding frame)
15
on the required side
of the marquee.
10. Attach the side hook and loop straps
16
to the telescopic legs
6
. (Fig. F)
11. Proceed in the same way with the other side wall
4
.
Q
Dismantling the marquee
1. Release the hook and loop straps
16
and remove the side walls
3
and
4
.
(Fig. G)
2. Release the pegs
5
on the ropes
2
and foot plates
11
.
3. Press the locking pin (telescopic leg)
9
in to retract the telescopic feet
10
.
(Fig. H)
4. Press the locking pin (folding frame)
8
in until you can move the sliding
clips
7
in each corner down. (Fig. I)
5. Push the marquee with the folding frame
1
evenly together with opposite
telescopic legs
6
. (Fig. J)
6. Pack the marquee with the folding frame
1
an accessories carefully in the
storage bag.
Q
Cleaning
j
For cleaning and the removal of any stains you should only use a
cleaning agent which is specifically designated for use with this product.
j
Remove any dirt from the product with a soft sponge and clean water.
j
Never wash the product in a washing machine.
j
Never used petrol, solvent or other cleaning agents.
j
Do not use any sharp objects, as these will damage the coating.
j
Allow all parts to dry thoroughly before you pack the product up again.
This will prevent the formation of moulds, odours and discolouration.
Q
Disposal
The packaging is made entirely of recyclable materials, which
you may dispose at local recycling facilities.
Contact your local refuse disposal authority for more details of how to dispose
of your worn-out product.
Product Description:
Gazebo
Model No.: Z29850A
Version:
01 / 2011
