8 FKM 2400 A1
GB
IE
Step 5
Insert the collecting container ♦ 5 into the sweeper.
Handling and operation
By pushing the sweeper the plate brushes 3 and sweeping brushes are set into
rotatation via belt drives. The rotating plate brushes 3 sweep the dirt to the
middle. The dirt is then lifted up by the two sweeping brushes and carried into
the collecting container
5 .
Height adjustment of the plate brushes
Depending on the application and wear and tear, the plate brushes 3 can be
steplessly adjusted in their operating height.
To do this, turn the adjustment screw 4 to the right to raise the plate brushes 3 ,
resp. to the left to lower the plate brushes 3 .
Height adjustment of the push bar
The push bar can be adjusted in three stages, to the heights of approx. 99 -
95 - 90 cm.
Remove the lock nuts and associated mounting screws .
Select the one pair of the 3 sets of holes on the push handle upper element
best suited to your needs and then rescrew the push bar fi rmly together with the
lock nuts
and the mounting screws .
5
