4 GB/IE
Safety advice / Installation
preset; they may spring back.

Never remove any screws from parts of the
housing.
CAUTION! RISK OF INJURY! Never let
the hose spring back by itself. Guide it careful-
ly back into the housing.
CAUTION! RISK OF INJURY! Never let go
of the hose if the automatic stop function is not
engaged.
CAUTION! RISK OF INJURY! Never
allow the hose to retract freely. This could result
in damage to the product.

Never block the hose end with your fingers or
other objects during use.

To avoid frost damage, remove the hose reel
from the wall and store it dry during winter.
CAUTION! DANGER OF SLIPPING!
Ensure that the ground near the hose reel is
kept as dry as possible.
 Turn the tap into the off position when the hose
reel is not in use.

The hose is not suitable for
delivering drinking water.
 Installation
 Fitting the water
hosepipe attachment

Guide the short length of hosepipe attachment
4 from outside through the opening into the
side compartment of the hose reel. Remove the
screw-on cap from the hose reel hose connection
and guide it onto the hosepipe attachment
4
(see Fig. A).

Insert the hosepipe attachment 4 firmly into
the toothed connection piece and screw the
cap back on (see Fig. B).

Close the side compartment with the side cover
3 (see Fig. C).
 Choosing the installation site
The hose reel is intended for outdoor use only and
cannot be connected to indoor taps.

Choose a part of the wall surface with approx.
50 cm free to each side so that the hose reel
can be turned through 180°.

If you wish to take the hose around a wall corner,
mount the hose reel at least 1 m from the
corner and use a hose guide (not included).
Note: To prevent backflow do not install the hose
reel higher than the tap.
Or: Install a reflux preventer or a pipe interrupter
between tap and hose.
 Mounting the wall holder
Important! The holder must be mounted
vertically (see Fig. E).

Use the four screws and dowels supplied. They
are suitable for mounting on brick, concrete or
wooden walls only. For mounting on other ma-
terials please use suitable screws and dowels.
Enquire in your local DIY shop for some suitable
screws and dowels for your particular wall.
 Mounting the hose reel

Push the hose reel 2 on to the wall holder 1
(see Figs. F + G).

Attach the tap attachment 5 to the free end of
the hosepipe attachment 4 and screw it on to
the water hosepipe connector 6 (see Fig. D).

Push the hosepipe connector with water stop
function 10 and the spray nozzle 9 on to the
long garden hose.

Check that the hose reel 2 can turn through
180° (see Fig. H).

Before first use turn the tap on and allow water
to run through the garden hose.

Check the device for leaks and tighten any
loose connections if necessary.
