ENGLISH -
DESCRIPTION
ASSEMBLY OF GRASS CATCHER
MULCHING CAP INSERTION
To cut the grass with the mulching system (no grass collection), lift the rear deflector panel and
insert the cap by fixing it with the spring as shown in the figure.
ADJUSTMENT OF CUTTING HEIGHT
ASSEMBLY UPPER HANDLES
ASSEMBLY LOWER HANDLES
1 Upper handles
2 Lower handles
3 Fastening knobs for upper handles
4 Grass catcher
5 Oil filler cap
6 Deck
7 Adjusting lever for cutting height
8 Spark plug
9 Fuel cap
10 Engine start-grip
11 Rear deflector
12 Engine stop lever
13 Clutch lever
3
Cutting height is adjusted with the lever located by the right rear wheel as shown in fig F.
Increase cutting height by moving the lever backwards and decrease cutting height by moving
it forward.
There are 6 steps availible (30, 39, 51, 64, 79, 95mm).
IV. Maintenance and Storage
 Keep all nuts, bolts and screws tight to be sure
the equipment is in safe working condition.
 Never store the equipment with petrol in the
tank inside a building where fumes may reach
an open flame or spark.
 Allow the engine to cool before storing in any
enclosure.
 To reduce the fire hazard, keep the engine,
silencer, battery compartment and petrol storage
area free of grass, leaves, or excessive grease.
 Check the grass catcher frequently for wear or
deterioration.
 Always use the recommended spark plug type.
Use of the wrong spark plug can damage the
piston/cylinder.
 Replace worn or damaged parts for safety.
Always use genuine spare parts.
 If the fuel tank has to be drained, this should
be done outdoors.
