Spraying, Cleaning and care, Clean the pressure sprayer – Florabest Z31339 Benutzerhandbuch
Seite 9: Clean the suction hose, Store the pressure sprayer
9
GB/IE
Press the pump handle
1
downwards
into the recesses.
Now take the spray tube
8
out of the
holder.
Spraying
Hang the pressure sprayer over your
shoulder by the carrying strap
6
.
Note: Ensure that the pressure sprayer
is always kept upright. Only when held
in this orientation will the sprayer work
properly.
Hold the spray tube firmly by the han-
dle
11
and direct the adjustable spray
nozzle
7
e.g. at a plant.
Press the trigger
13
to start the spraying
process.
Release the trigger
13
to stop the
spraying process.
Note: When the pressure in the con-
tainer
5
is no longer sufficient to spray,
pump the container
5
to increase the
pressure again up to but not exceeding
the maximum permissible operating
pressure of 2.5 bar. You can check the
operating pressure using the pressure
gauge
4
(see “Building up the operat-
ing pressure”).
Pull the safety valve
3
upwards as far
as it will go to release the residual pres-
sure in the container
5
.
Cleaning and care
If the nozzle seems to be blocked, do
not try to blow it free with your mouth.
Note:
Clean the pressure sprayer after
each use!
Clean the pressure
sprayer
Unscrew the spray nozzle
7
.
Clean the spray nozzle
7
under running
water.
If the spray nozzle
7
is clogged,
clean it by pushing a needle through it.
Flush through the pressure sprayer,
pipes and tubes with water.
Clean the surfaces of the product with
a moist cloth.
Clean the suction hose
Clean the suction hose
12
as follows:
Loosen the union nut of the suction hose
9
on the container
5
.
Pull the suction hose
12
out of the
tank
5
.
Clean the suction hose
12
under running
water.
After cleaning, insert the suction hose
12
back in its opening on the tank
5
.
Tighten the union nut
9
hand-tight.
Store the pressure
sprayer
Release any residual pressure still present
in the container after use. To do this,
pull the safety valve button upwards
until you can no longer hear the hiss of
escaping air.
Thoroughly clean the device and allow
it to dry before you put it away for the
winter. This will avoid frost damage.
Clean the pressure sprayer before storing
it away.
