7
FKG 48 A1
GB
CY
Step 3
♦
Secure the ventilation plate
9
with a M5 x 12 screw
B
, Ø6 washer
F
and M5 nut
G
to the fi rebowl
8
.
♦
Secure the two handles
using M5 x 12 screws
B
, Ø6 washers
F
,
Ø6 washers
E
and M5 nuts
G
to the fi rebowl
8
.
♦
To fi nish the assembly, tighten all screw connections fi rmly.
Step 4
♦
Clamp the ash collector tray
12
in the ash collector tray holder
11
between
the legs (
13
+
16
). Place the charcoal grill
7
and the cooking grill
5
into
the fi rebowl
8
. If needed, place the charcoal divider
6
on the charcoal
grill
7
.
B
G
F
E
8
9
B
B
E
5
6
7
8
11
13
16
12
