Items supplied
3 x Handle
2 1 x Ventilation plate (hood)
3 1 x Hood
4 1 x Hood holder
5 1 x Cooking grill
6 2 x Charcoal divider
7 1 x Charcoal grill
8 1 x Firebowl
9 1 x Ventilation plate (fi rebowl)
10 3 x Leg Caps
11 3 x Ash collector tray holder
12 1 x Ash collector tray
13 2 x Wheeled legs
14 2 x Wheels
15 1 x Wire shelf
16 1 x Support leg
Connection elements
A B C D E F G H
M6x30
3x
M5x12
8x
Ø8
2x
Ø6
3x
Ø6
6x
Ø6
8x
M5
8x
M8
2x
NOTICE
► Check the contents to ensure everything is available and for signs of visible
damage.
► If the delivery is not complete or is damaged due to defective packaging or
through transportation contact the Service Hotline (see chapter Service).
