11 GB/IE/CY 11
GB/IE/CY
Installation Installation / Replacing the rechargeable batteries
including the floor light. Bear in mind
that the decorative collar
2 must be
placed on top of the substrate sur-
face later (see Fig. G).
3. Pour a little mixed concrete into the
predrilled hole.
4. Place the floor insert in the hole and
let the concrete harden (see Fig. D).
Follow the manufacturer’s instructions.
5. Assemble the product as shown in
Figs. A and D.
6. Press the ON / OFF button 9 to
switch on the light (see Fig. C).
7. Insert the light body 5 into the
floor insert (see Fig. E).
8. Fix the light body and floor insert to-
gether with the screws 12 (see Fig. E).
9. Install the product as shown in Fig. F.
Your light is now ready for operation.
Replacing the
rechargeable batteries
Replace the rechargeable batteries when
you notice that the period of illumination
provided by the light has considerably
reduced over time, despite full exposure
to solar radiation.
Note: Ensure that you switch off the light be-
fore you replace the rechargeable batteries.
Note: To do this you will require a cross-
head screwdriver and a hexagon key.
Change the rechargeable batteries
as shown in Figs. A, B and C.
Note: Make sure you fit the batteries
the right way round (polarity). The
correct polarity is shown inside the
battery compartment.
Note: Ensure that the light is correctly
assembled and installed before use.
