Livarno 2304/031L - Handbuch

GB/IE GB/IE GB/IE GB/IE
LED class: 2
Q Safety
Safety advice
The right to claim under the guarantee shall
be rendered invalid in respect of damage
caused by the non-observance of these oper-
ating instructions! No liability is accepted for
consequent damage! No liability is accepted
for damage to property or persons caused
by improper handling or non-observance of
the safety advice!
Warning! Danger to life!
Batteries are not intended to be in the
hands of children. Do not leave batteries
around unattended. They could be swal-
lowed by children or pets. In the event of
swallowing a battery, contact a doctor
immediately!
m important! This device is not a toy!
J Do not leave small children unattended
with the device!
Warning!
Do not short-circuit the
batteries. Overheating, fire or destruction
of the batteries might result.
Warning!
Danger of explo-
Sion! Never throw the batteries into
fire or water. Never recharge the batteries!
The batteries might explode.
J Wear protective gloves!
Exhausted or damaged batteries
may irritate the skin on contact,
so always wear suitable protective gloves
Under-cabinet leD light
Q proper use
This LED light is suitable exclusively for provid-
ing illumination in dry interior rooms in a private,
domestic environment. The LED light should be
positioned within reach so that the switch can
be operated conveniently. It must be operated
with batteries only.
Q included items
1 x Under-cabinet LED light
6 x Batteries micro 1.5 V / AAA
2 x Screws
2 x pile and loop fastening strips, double-sided
1 x Operating instructions
Q Description of parts
1 On/Off switch
2 LED spot
3 pile and loop fastening strip
4 Screws
5 Mounting plate
6 Fastening pin
7 Battery compartment
8 Battery compartment cover
Q technical information
Article No.: 2304 / 031L
power supply: 6 x batteries micro
1.5 V / AAA
in these circumstances.
J Never place the device in conditions of
high temperature or moisture, as this may
damage the device.
J Never use the device in a potentially
explosive atmosphere.
J leD radiation! Avoid the
risk of eye damage! Do not
look into the LED beam.
J The LEDs cannot be replaced!
J In the event of damage, repairs or other
problems with the light please contact the
Service Centre or an electrician.
Working safely!
J Do not subject the light to mechanical
loads!
J Operate the light using batteries type
AAA / 1.5 V only. Ensure that all the
batteries have the same state of charge!
Q preparations for use
Q inserting / replacing
the batteries
j Hold the LED light with its back upwards
and the On / Off switch
1 facing for-
wards.
j Slide the mounting plate 5 to the left
and remove it from the LED light.
j press the clip of the battery compartment
cover
8 to the side and remove one or
both battery compartment covers.
j Insert the 6 batteries type micro 1.5 V / AAA
into the battery compartments 7 , ob-
serving the correct polarity (+ and -).
j Replace the battery compartment covers 8
on the battery compartments 7 , making
sure they engage properly.
note: Take the batteries out of the battery
compartment
7 if you intend not to use light
for an extended period. Batteries can leak.
note: As the battery voltages drops, the
light becomes weaker.
Q fastening in place with
pile and loop strip
note: Remove the mounting plate 5 if you
wish to use this form of fastening.
m important! Check that the substrate on
which you intend to fasten the device is
dry, smooth and free of dust and grease.
j pull the protective film from one of the sides
of the pile and loop fastening strip
3 .
j press the pile and loop fastening strip 3
using firm pressure on to the areas pro-
vided for this purpose on the right and
left of the underside of the LED light.
j Now pull the protective film from the other
side of the pile and loop fastening strip
3 .
j press the LED light on to the desired sub-
strate. press carefully but with firm pressure
for about 5 seconds.
j To remove the LED light (e.g. to replace
the batteries), pull the LED light carefully
from the pile and loop strips
3 .
LED-UNTERBAULEUchTE
Bedienungs- und Sicherheitshinweise
2304/031L
UNDER-cABiNET LED LighT
3
KAAPiN ALLE ASENNETTAVA
LED-VALAiSiN
Käyttö- ja turvaohjeet
LED-UNDERBELySNiNg
Bruksanvisning och säkerhetsanvisningar
LED-iNDBygNiNgSSPOT
Brugs- og sikkerhedsanvisninger
UNDER-cABiNET LED LighT
Operation and Safety Notes
LED-STRAHLUNG
NICHT IN DEN STRAHL BLICKEN
LED-KLASSE 2
EN 60825-1/A2:2001
DIODESTRÅlING
SE IKKE IND I STRÅLEN
DIODE-KLASSE 2
EN 60825-1/A2:2001
LEDSTRÅLNING
TITTA INTE DIREKT IN I LJUSSTRÅLEN
LED-KLASS 2
EN 60825-1/A2:2001
LED-SÄTEET
ÄLÄ KATSO SÄTEISIIN
LED-LUOKKA 2
EN 60825-1/A2:2001
LED RADIATION
DO NOT LOOK INTO THE BEAM
LED CLASS 2
EN 60825-1/A2:2001
p ≤ 0,550 mW
λ = 451 nm
2
3 4 5
7
8
1
6
