Safety Information / Before installation / Installation / Maintenance and cleaning
J Install the light only on a stable surface
(e.g. masonry).
J Before wall installation, check whether the
chosen wall is suitable to hold the light. If
necessary, you can obtain further information
from a specialist store.
J Find out which installation material is suitable
for your wall before installing the light.
J The light is supplied with installation material
suitable for standard, solid masonry.
J Install the light so that it is protected against
extreme moisture, wind and dirt.
J Do not install the light above a heat source.
Q Before installation
Important: the electrical connection must be made
by a qualified electrician or a person authorised
to perform electrical installations. This person must
be familiar with the properties of the light and all
connection regulations.
J Before installation, please familiarise yourself
with the instructions and illustrations in this
operating manual and with the light itself.
J Make sure that before installation there is no
voltage on the line you will be connecting the
light to. To do this, remove the fuse or switch off
the circuit breaker in the fuse box (0 position).
J Check that there is no voltage using a voltage
tester.
Q Installation
Note: you will need an electric drill to install the light.
m CaUTION! rISK OF INJUrY! Please read
the operating instructions for your drill.
j Remove the screws 4 unscrewing them in anti-
clockwise direction and place them 4 and the
washers 3 carefully on one side.
j Position the mount bracket 6 on the wall and
mark the drill holes using a pencil or similar.
Use a spirit level to help you if necessary.
j Drill the holes (ø 6 mm, depth approx. 35 mm).
Take care not to damage the connecting cable
when drilling.
j Insert the dowels 8 into the drilled holes.
If necessary use a rubber hammer.
j Screw the mount bracket 6 to the wall using
the screws 5 supplied.
j To open the junction box 10 , unfasten the
screws 9 in anticlockwise direction.
j Push the supply cable (external connection
from the house)
7 through the cable conduit
on the junction box 10 .
j Connect the supply cable (external connection
from the house)
7 using the pre-assembled
wire terminal 11 to the connecting cable on
the light.
Note: make sure that you connect the individual
wires of the supply cable (external connection
from the house)
7 correctly: live conductor:
black or brown = symbol L; neutral conductor:
blue = symbol N; earthing conductor: green
and yellow = symbol .
j Place the wire terminal 11 inside the junction
box 10 and replace the cover on the junction
box 10 . Tighten the screws 9 in clockwise
direction.
j Place the light onto the mount bracket 6 and
fix it using the washers 3 and screws 4 .
Q Maintenance and cleaning
WarNINg! DaNgEr TO LIFE BY
ELECTrIC SHOCK! Before carrying out any work
on the light, switch the electricity supply off at the fuse
box or remove the screw-in fuses from the fuse box.
WarNINg! DaNgEr TO LIFE BY
ELECTrIC SHOCK! For electrical safety the light
must never be cleaned with water or other liquids,
or immersed in water.
J Do not use solvents, benzene or similar products.
j Allow the light to cool down for approx.
5 minutes before carrying out any work.
j Use only a dry, lint-free cloth to clean the light.
j The LEDs 2 cannot be replaced.
