6 GB/IE
Directing the lamps / Installation / Maintenance and cleaning / Service
Release the screw of the cable holder 14 using
the hexagonal key 13 . Retighten the screw
when you have finished setting the height (see
Figs. C–F).
Note: The height adjuster fixes the height of
the light to the desired height (600–1200 mm).
Installation
Note: you will need an electric drill to install the
light.
CAUTION! RISK OF INJURY! Please read
the operating instructions for your drill.
Remove the screws 3 on the side of the con-
nection enclosure 7 .
Remove the mounting bracket 2 from the con-
nection enclosure.
Mark the positions for the drilled holes on the
ceiling using the predrilled holes in the mounting
bracket as a guide.
Now drill the fixing holes.
CAUTION! Ensure that you do not damage
any cables in the ceiling.
Insert the dowels 1 into the drilled holes.
Fix the mounting bracket to the ceiling with the
screws 4 .
Now connect the connection cable of the light
to the mains connection cable (external) 6 by
means of the terminal block 5 .
Note: Ensure that each wire of the mains
connection cable (external) is properly con-
nected in the correct place: live wire, black or
brown = symbol L, neutral wire, blue = symbol N,
protective earth wire, green-yellow = symbol .
Fix the light to the mounting bracket with the
screws.
Unscrew the screws 12 in the lamp fittings 9 .
Insert the energy-saving bulbs 10 and place
the lamp glasses 11 on the fittings. Tighten the
screws again.
Note: Use a clean, fluff-free cloth when you
are inserting a bulb.
Your light is now ready for operation.
Maintenance and cleaning
DANGER TO LIFE BY ELEC-
TRIC SHOCK! Before carrying out any work on
the light, switch the electricity supply off at the fuse
box or remove the screw-in fuses from the fuse box.
DANGER TO LIFE BY ELEC-
TRIC SHOCK! For electrical safety the light must
never be cleaned with water or other liquids, or
immersed in water.
Replacing a bulb
DANGER TO LIFE BY ELEC-
TRIC SHOCK! Before carrying out any work on
the light, switch the electricity supply off at the fuse
box or remove the screw-in fuses from the fuse box.
CAUTION! RISK OF BURNS! Allow the
light to cool down completely.
Note: Use a clean, fluff-free cloth when you are
replacing a bulb.
Use 230 V∼ energy-saving bulbs with an E14
fitting and a maximum power of 9 watt only.
Replace the bulbs in accordance with Figs. A
and B.
Cleaning
CAUTION! RISK OF BURNS! Allow the
light to cool down completely.
Do not use solvents, petrol etc.
Use a dry fluff-free cloth when you are cleaning.
Service
GB
Service Great Britain
Tel.:
0871 5000 720 (0,10 GBP/Min.)
e-mail: [email protected]
IAN 66143
