13
Motor
Drive Brushless Direct-drive, Quartz stabilised
Speed settings 33/45/78
Wow & Flutter < ±0,07 % (DIN WTD)
Tonearm
Auto-Start/-Stop-Function Auto-Stop with automatic tonearm lift
Bearing 4 x Pivot ball-bearing / twin Gimbal Mounting
Effective length 221,5 mm
Offset Angle 25,6°
Overhang 19 mm
Type statically balanced
Stylus Pressure Range 0 to 4 g
Cartridge Weight Range 5 g to 9 g
Factory installed Pick-up Ortofon 2M Blue
Replacement Stylus Ortofon Stylus 2M Blue
Platter
Material Aluminium Die-cast, Rubber Damping Inserted
Mat Rubber 2,5 mm
Bearing Hardened Steel Motor Spindle, Brass Bushing
Diameter 305 mm
Weight incl. Mat 1450 g
Plinth
Surface finish Vinyl veneer: Black / Paint: Black Gloss / Wood Veneer: Walnut
Feet Ø 62 mm / Elastomer Damping Element
Connection RCA socket
Connection to Phono Input YES
Connection to Line Input YES
Digital Output X
Dimension (closed dust cover) 435 x 367 x 145 mm
Dimension (open dust cover) D: 415 mm / H: 400 mm
Weight 7 kg
Power Supply
The efficiency readings were taken with an input Voltage
of 230 V AC at 50 Hz
Type FJ-SW1202000N
Input Voltage 100 (-10 %) V AC to 240 (+10 %) V AC
Frequency 50 / 60 Hz
Output Voltage 12 V DC
Output Current 2,0 A
Output Watt 24 W
Average Efficiency During Operation ≥ 86.2% @average of 25/50/75/100% loads 115&230VAC input
Power Consumption at Idle < 0,1 W
Technical Specifications
