Technical data
1) According to EN 60728-3; CENELEC channel plan 42 carriers
2) According to EN 60728-3 (category C); from 40 MHz 14 dB-1.5 dB/octave, but 10 dB
Type VOS 32/F
Order no. 20910020
Forward path
Frequency range MHz 47 (85)-862
Gain (switchable) dB 26/32
Amplitude ripple dB ± 1.5
Attenuator setting range dB 0-20
Equaliser setting range dB 0-20
Interstage variable attenuator setting range
(can be switched with jumpers)
dB 0/6
Interstage equaliser setting range
(can be switched with jumpers)
dB 0/6
Maximum operating level 1) (60-dB-CTB/CSO)
- fl at
- with 6-dB interstage pre-emphasis dBµV
dBµV 100
102
Noise fi gure dB 7/6
No. of outputs 1
Return path
See VGR 28/xx data
General
Impedance input/output Ω 75
Return loss input/output 2) dB 14
RF connections F-type connector
Test socket output with directional coupler (5-862 MHz) dB -20
Test socket output return path (5-65 MHz) dB -20
Supply voltage V
AC
198-253
Power consumption (without/with return path amplifi er) W 4/5
Indication of operation mode Green LED
Protection class II
Protection category (according to EN 60529) IP 50
Temperature range °C -20 to +55
Dimensions mm 184 x 134 x 63
Packing unit/weight pc./kg 1 (10)/1.7
Basic safety precautions
Caution!
The amplifi er supply voltage is 230-V AC
and is dangerous on direct physical contact!
• Do not touch live parts
• The power plug must be easily operable as the means of cutting power to the amplifi er,
i.e. the wall outlet must be close to the amplifi er and easily accessible
• The power must be cut when installing or removing the amplifi er
• Do not operate the amplifi er if the standard power supply protective cover is not fi tted.
