12
GB IE
When starting to charge and while
charging, the battery charge indicator
( 19) lights up red.
When charging is over, the light
changes to green.
1. Remove the battery (16) from the
appliance, as necessary.
2. Inser the battery (16) in the
charging compartment of the bat-
tery charger (19). It will audibly
snap in.
3. Plug the battery charger (19) into
a mains outlet.
4. When the battery is fully re-
charged unplug the battery
charger (19) from the mains.
5. Press the release button ( 17)
on the battery (16) and pull the
battery out of the battery charger
(19).
Used batteries
• If a fully recharged battery lasts for
considerably shorter operating times,
the battery is used up and needs to be
replaced. Only use an OEM battery
pack replacement available from our
Customer Service.
• Always take heed of the applicable
safety instructions as well as the envi-
ronmental protection regulations and
information (see “Cleaning and Main-
tenance”).
Assembling instructions
. Do.not.insert.the.battery.until.
the.appliance.is.fully.assem-
bled..Risk.of.injury!
To.put.on.the.protective.
cover:
1. Place the protective cover (14) on
the motor head (10) and screw it
down with the 3 Phillips screws.
To.put.on.the.auxiliary.
handle:
2. Pull the ends of the auxiliary han-
dle (5) to extend the handle and
slide it over the handle holder
(22).
3. Screw down the screw (23) in the
auxiliary handle (5).
Mounting.the.trimming.unit:
. 4. Slip the cutting disc (12) onto the
axle. There is only one mounting
position. Screw the cutting disc
(12) to the axle. Mind the left-
hand thread.
Place the cutting insert (13) on
the pin (23) on the cutting disk
(12) and pull out the insert until it
snaps in.
Spare cutting inserts are kept in the
box (4) on the auxiliary handle (5).
To.insert.the.battery:
5. To insert the battery (16), place it
on the guide track (20) and push
it into the appliance. It will audi-
bly snap in.
Operation
. Caution:.risk.of.injury!.Do.not.
operate.the.appliance.with-
out.the.protective.cover..To.
operate.the.appliance,.wear.
suitable.clothing,.eye.and.ear.
protection..
. Prior.to.every.use,.check.that.
the.appliance.is.operative..Do.
