5
IE GB
Functional description
The trimming assembly of the manually
controlled, portable, battery-operated
lawn trimmer consists of a system of plastic
knife/cutting insert.
The appliance also features a pivoting mo-
tor head, adjustable aluminium telescopic
shaft, and a spacer bow.
A hood covering the cutting device protects
the user.
The following describes the functions of the
operating parts.
This equipment is not suitable for commer-
cial use.
Commercial use will invalidate the guar-
antee.
Technical data
Appliance
Motor voltage .......................... 18 V
Idling speed ...............8000 min -1 (rpm)
Protection Class ............................... III
Runtime ..........................max. 50 min*
Cutting circle .............................25 cm
Weight (without battery charger) ... 2.1 kg
Sound pressure level
(L
pA
) ..............71.3 dB(A), K
pA
= 3 dB(A)
Sound power level (L
wA
)
guaranteed ........................94 dB(A)
measured .....89 dB(A); K
wA
=1.94 dB(A)
Vibration (a
n
)
upper handle .1.098 m/s 2 , K=1.5 m/s 2
additional handle
..................... 1.539 m/s 2 , K=1.5 m/s 2
Battery.(Li-Ion)
Nominal voltage ...................... 18 V
Capacity ..................................1.5 Ah
Charging time ................... approx. 5 h
Recharger............. JLH082100350G
Nominal consumption ................. 12 W
General description
Extent of the delivery
Carefully unpack the trimmer and check
that it is complete:
- Battery-operated lawn trimmer
- Protective cover
- Auxiliary handle
- 20 Cutting inserts
- Battery charger
- Battery
The illustrations are on the front
fold-out page.
Overview
1 Top handle
2 On/Off switch
3 Switch lock
4 Box for cutting inserts (not visible)
5 Auxiliary handle
6 Handle rod
7 Lock of handle rod adjustment
8 Threaded bush for length adjust-
ment
9 Telescopic shaft
10 Motor head
11 Spacer bow (flower guard)
12 Cutting disk
13 Cutting insert
14 Protective cover
15 Bar for tilt angle adjustment
16 Battery
17 Battery release button
18 Battery charge state indicator
19 Battery charger
20 Guide track
21 Handle holder
22 Handle screw
23 Pin
