10
GB IE
Assembling
instructions
Prior to any work on the implement
always disconnect the plug from the
power socket!
Assembling the handle bar
B 1. Insert the lower bar (8) into the
implement case (10) and screw
it on with the two Philips screws
(28).
2. Secure the two centre bars (15)
to the lower bar (8) with the
screws and wing nuts (5b).
The two centre bars can be secured
in two positions to adjust the handle
bar to your height.
3. Hang the cable strain relief
(19a) on the upper handle bar
(4).
Attach the clip ring to the tension
adjuster bracket (19b) beneath
the cable tension adjuster (19a)
on the upper handle (4).
4. Use the screws and wing nuts
(5a) to firmly secure the upper
handle bar (4) to the two centre
bars (15).
5. Fasten the electric cable (16)
to the bar with the two cable
clamps (14a+b).
Mounting and emptying the
collection bag
WARNING: Never operate
the implement without the
impact protector. Danger of
Injury!
Assembling.the.collection.bag:
The collection bag is delivered in a folded
state and must therefore be assembled be-
fore it is mounted on the implement.
C 1. Assemble the collection bag rods
(22).
2. Slip the plastic straps (24) over
the collection bag rods.
Mounting.the.collection.
bag.on.the.implement:
3. Lift the impact protector (9).
4. Push the pins (23) on the collec-
tion bag rods into the socket in
the implement case (10).
5. Release the impact protector so
that it holds the collection bag
(6) in its position.
Removing.and.emptying.
the.collection.bag:
6. Lift the impact protector (9) and
take out the collection bag (6).
Operation
Please observe local regulations
concerning noise protection. It is
quite possible that local rules and
regulations may limit the time of
implement operation or even pro-
hibited its use on certain days (e.g.
Sundays and holidays), and dur-
ing certain times of the day (noon,
night hours) and in certain areas
(e.g. spars, clinics, etc.).
Setting the working positions
The implement has 5 principal position set-
tings:
Setting.0.:. Transport.position
This position sets the maximum safety spac-
ing between the tool and the floor.
