General description
Scope of delivery
Carefully unpack the implement and check
that all the subsequently listed parts are
complete:
• Implement case with verticuttor cylinder
and impact protector
• Aerating cylinder
• Upper handle bar complete with start-
ing lever, power plug, unlocking button
and firmly mounted power cable
• Lower bar
• 2 centre bars
• Collection bag
• Cable strain relief
• 2 cable clamps
• Mounting accessories:
- 2 Philips screws, 4 screws and 4
wing nuts to fasten the bar
- Spanner to change the cylinders
• Instruction Manual
Ensure during assembly that the
power cable is not squeezed and
that it has sufficient play.
Overview
.The.most.important.
functional.parts.are.il-
lustrated.on.the.cover.
page.
A 1 Unlocking button
2 Power cable (10 m)
3 Starting lever
4 Upper handle bar
5a+b 4 screws and 4 wing nuts to se-
cure the bar
6 Collection bag
7 Handle on the Collection bag
8 Lower bar
9 Impact protector
10 Implement case
11 2 wheels
12 2 rear wheels
13 Setting button
14a+b 2 cable clamps
15 2 centre bars
16 Electric cable
17 Spanner
18 Tool holder
19a Cable strain relief
19b Tension adjuster bracket
20 Aerator cylinder with sprung
tines
21 Verticutor cylinder with knives
C 22 Collection bag rods
23 Pins
24 Plastic straps
E 25 Fastening screw
26 Bearing cover
F
27 Shaft
Functional description
The verticuttor and lawn aerator has two
easily exchangeable work cylinders:
An aerator cylinder made of hard plastic
with vertically rotating sprung tines, and a
verticutor cylinder with vertically mounted
high-grade steel knives.
The implement features a high-quality plas-
tic case with collection bag and a handle
bar with a folding function. Please refer to
the subsequent descriptions for the actual
functions of the individual control elements.
Technical data
Electric.Scarifier./
Aerator....................... FLV.1300.A2
Motor input .............................. 1300 W
Rated voltage ...................230V~, 50 Hz
Protection Class ............................... II
Degree of protection .........................IPX4
Rotating speed of the tool (n
o
)
......................................3600 min -1 (r.p.m)
Cylinder width ...........................360 mm
Readjustment range for wear ...........9 mm
Weight (without collection bag) ... 11.4 kg
