Scope of delivery / part names
1 x handle for hood
2 3 x ventilation plates
3 1 x hood
4 1 x cooking grill
5 1 x handle for cooking grill
6 1 x charcoal bowl
7 1 x firebowl
8 3 x bracket closures
9 3 x brackets
10 3 x support legs
This operating manual
Assembly material
A B C D E F
M6x60
1x
M6x30
3x
M5x10
4x
M3x10
6x
Ø6 x 25
3x
Ø6 x 16
1x
G H I J K L
Ø6 x 12
3x
Ø5
4x
M5
3x
M3
6x
M6
1x
M5
1x
NOTE
► Check the contents for completeness and for signs of visible damage.
► If the contents are not complete, or are damaged due to defective packaging
or through transportation, contact the Service Hotline (see chapter
Service).
