17 GB
Start-up
Feed the power cord (external) 12 through the
cable guides 13 .
Insert the dowels 1 into the bores.
Model 2764-062L and 2788-068L and
2787-062L
Fasten the mounting bracket 2 with the
provided screws 3 .
Now connect the external lead of the light to
the mains cable (external)
12 using the termi-
nal block 14 .
Note: Be sure to correctly connect each of the
individual wires of the mains connection cable
(external): live wire, black or brown = symbol
L, neutral wire, blue = symbol N, earth wire,
green-yellow = symbol .
Now use the screws 3 to screw the light to
the mounting bracket 2 .
Align the lamp arm 5 in the desired direction
(2788-068L and 2764-062L).
Mark the mounting holes for the ceiling
mount
7 . Be sure the bores are always lo-
cated between two spotlights 10 . This ensures
a more secure hold.
Make the mounting holes (approx. 6 mm,
approx 40 mm deep) for the ceiling mount
7 .
Insert the plugs 6 into the bores. Secure the
ceiling mount 7 using the included screws
(small screw head).
Screw the ceiling mount clips 9 into the
ceiling mount 7 .
Clamp the lamp arms 5 into the ceiling mount
clips 9 .
Use a clean, lint-free cloth to insert the light
bulbs.
Insert the light bulb by screwing in the GU10
light bulb with a ¼ turn clockwise (model
2787-062L) or by carefully screwing the E14
light bulb in clockwise (model 2788-068L and
2787-062L). Ensure that it is properly seated.
Model 2788-068L and 2787-062L
Push a protective ring 16 into the opening in
each light glass 17 .
Secure the lamp glass 17 to the spotlight 10
using the pins 15 .
Screw the light bulb 18 clockwise into the
socket. Check for correct seating.
Your light is now ready to use.
Reinsert the fuse or switch the circuit breaker
back on.
Directing the spotlight
Only change the direction of the spotlights 10
when the light is switched off.
Allow the lamp to cool off completely.
Position the individual spotlights 10 by their
base. The spots can be turned by approx. 320°.
Changing the bulb
CAUTION! RISK OF ELECTRIC SHOCK!
First disconnect the light from the mains when replac-
ing the lamp. To do so, remove the fuse or switch
off the circuit breaker in the fuse box (position 0).
Allow the light bulb to cool off completely.
Screw the defective GU10 LED light bulb
(2787-062L) or E14 LED light bulb
(2788-068L and 2787-062L) out of the socket
counter-clockwise.
Use a clean, lint-free cloth to replace a bulb.
Only use 220–240 V ∼ LED light bulbs with a
E14 base and a maximum output of 5,5 W
(2788-068L and 2787-062L) or LED light bulb
GU 10 with a maximum output of 5 Watt
(2787-062L).
Remove the light bulb by unscrewing the GU10
light bulb with a ¼ turn counter-clockwise
(model 2787-062L) or by carefully unscrewing
the E14 light bulb counter-clockwise (model
2788-068L and 2787-062L).
Install the new light bulb by screwing in the
GU10 light bulb with a ¼ turn clockwise
(Modell 2787-062L) or by carefully screwing
the E14 light bulb in clockwise (model 2788-
068L and 2787-062L). Check for correct
seating.
Reinsert the fuse or switch the circuit breaker
back on.
